Application scenarios and actual cases of high-pressure Irrigation hoses

The application scenarios of high-pressure irrigation hoses have expanded from traditional farmland irrigation to multiple fields. Its flexible adaptability makes it an important equipment for agriculture, gardening, industry and other industries. The following will introduce the main application scenarios by category and demonstrate its application effects with actual cases.

1. Agricultural irrigation: core application areas

Agriculture is the largest application area of high-pressure irrigation hoses, covering a variety of scenarios such as field crops, cash crops, and greenhouse planting. Its core value lies in improving irrigation efficiency and saving water resources.

(1) Field crop irrigation

In large-scale field planting of wheat, corn, rice, etc., high-pressure irrigation hoses are usually used in conjunction with reel sprinklers and center pivot sprinklers to achieve the integrated operation of "hose laying - high-pressure water spraying - automatic recycling". For example, in a 1,000-mu wheat planting base in Dezhou City, Shandong Province, a combination of "1.6MPa rubber high-pressure water hose + reel-type sprinkler" was used. Compared with traditional flood irrigation, it saved 60% of water per mu, shortened the irrigation cycle from 7 days to 2 days, and increased the yield per mu by 15%. (2) Irrigation of economic crops In the planting of economic crops such as fruit trees, vegetables, and flowers, high-pressure irrigation hoses need to meet the needs of precise irrigation. They are usually connected with drip irrigation belts and micro-spraying belts to achieve the conversion of "high-pressure transmission - low-pressure drip irrigation". Taking the 200-mu citrus orchard in Kunming City, Yunnan Province as an example, a "1.2MPa composite high-pressure water hose + drip irrigation system" was used. The high-pressure water flow was transported to the field drip irrigation main pipe through the water hose, and then accurately dripped into the roots of citrus through the drip irrigation belt. It not only saved 70% of water, but also reduced the loss of chemical fertilizers. The sweetness of citrus increased by 2-3 degrees, and the average income per mu increased by 3,000 yuan. (3) Greenhouse irrigation

The space in greenhouses is limited and the environment is closed, which places high demands on the portability and corrosion resistance of water hoses. Usually, PVC or PE high-pressure water hoses with a diameter of 25-50mm are selected and used with mobile sprinkler guns to facilitate flexible adjustment of irrigation positions. For example, a greenhouse vegetable base in Langfang City, Hebei Province, uses "1.0MPa PVC high-pressure water hose + handheld sprinkler gun" to shorten the irrigation time of a single greenhouse from 4 hours of traditional manual irrigation to 1 hour, and the water flow is uniform, and the incidence of vegetable diseases and insect pests is reduced by 20%.

2. Garden and lawn maintenance: refined demand scenarios

In urban gardens, parks, green spaces, golf courses and other scenarios, high-pressure irrigation hoses need to meet the requirements of refined maintenance while taking into account both aesthetics and durability.

(1) Urban garden maintenance

The trees, shrubs and flowers in urban gardens are scattered, and lightweight and easy-to-move high-pressure water hoses are required. For example, a municipal garden company in Beijing uses a "1.2MPa composite high-pressure water hose + small sprinkler" to irrigate the green belts on both sides of the city roads. The water hose is light and easy to fold, and can be easily carried to narrow areas, increasing irrigation efficiency by 50%. In addition, the color of the water hose is coordinated with the green belt, which does not affect the beauty of the city.

(2) Golf course maintenance

Golf courses have extremely high requirements for the uniformity and pressure stability of lawn irrigation, and usually use large-diameter, high-pressure rubber high-pressure water hoses. For example, a golf course in Shenzhen, Guangdong Province, uses a "2.0MPa rubber high-pressure water hose + high-pressure atomizing sprinkler system". The water hose can stably deliver high-pressure water flow, making the coverage of the atomizing sprinkler uniform, the lawn grows uniformly, and the maintenance cost is reduced by 30%.

3. Industrial and mining drainage: high-intensity use scenarios

In industrial production, mining and other scenarios, high-pressure irrigation hoses need to withstand high-intensity and high-corrosion use environments. They are mainly used for drainage and transporting industrial wastewater. (1) Industrial drainage

In factory workshops and industrial parks, High-pressure hoses can be used to discharge industrial wastewater or cooling water. For example, a machinery factory in Suzhou City, Jiangsu Province, uses "1.6MPa rubber high-pressure hose + drainage pump" to discharge cooling wastewater in the workshop. The hose is oil-resistant and corrosion-resistant, with a service life of more than 5 years and no need for frequent replacement.

(2) Mine drainage

A large amount of mine water is generated during mining, and it is necessary to use a high-pressure and wear-resistant hose for transportation. For example, a coal mine in Datong City, Shanxi Province, uses "2.5MPa steel wire reinforced rubber high-pressure hose + large drainage pump". The hose can withstand the high-pressure transportation requirements of mine water and has excellent wear resistance. It has a service life of 6 years in complex mining environments, reducing mine drainage costs.

4. Emergency and temporary water supply: flexible adaptation scenarios

In emergency scenarios such as flood disasters, droughts and water shortages, high-pressure irrigation hoses can be used as temporary water supply pipelines to achieve rapid water delivery. For example, when Henan Province suffered a drought in 2023, the local government mobilized a large number of "1.6MPa composite high-pressure water hoses" to connect rivers and dry farmland, build temporary water pipelines, and complete emergency irrigation of 20,000 mu of farmland in just 3 days, alleviating the drought.

V. Installation, maintenance and common problem solving of high-pressure irrigation hoses

Proper installation and maintenance are the key to extending the service life of high-pressure irrigation hoses and ensuring their safe use. The following will introduce in detail the installation steps, daily maintenance methods and solutions to common problems of high-pressure irrigation hoses.

1. Correct installation steps: ensuring safety and efficiency

(1) Preparation before installation

Check the appearance of the hose: confirm that the hose is not damaged, cracked, or aged, and the interface is not deformed or leaking;

Match the interface specifications: ensure that the hose interface is consistent with the interface specifications of the water pump and sprinkler equipment to avoid leakage due to interface mismatch;

Clear the paving path: remove sharp stones, branches and other obstacles on the paving path to avoid scratching the hose. (2) Installation process

Connect the water source interface: Connect the interface at one end of the hose to the water outlet of the water pump, and ensure that the connection is firm (the quick connector needs to be clamped, and the threaded connector needs to be tightened);

2. Lay the hose: Lay the hose according to the irrigation needs, avoid excessive bending or twisting (the bending radius should be ≥ 5 times the hose diameter), and keep the hose flat and without wrinkles;

3. Connect the terminal equipment: Connect the other end of the hose to the sprinkler, drip irrigation system or sprinkler gun, and also ensure that the connection is firm;

4. Water test inspection: Turn on the water pump and slowly increase the pressure to the working pressure. Check whether the hose has leakage, bulging, and whether the interface is well sealed;

5. Fix the hose: In areas with large slopes, use soil blocks or sandbags to fix the hose to prevent the hose from moving under the action of high-pressure water flow. (3) Installation precautions

Avoid direct contact of the hose with high-temperature objects (such as the engine exhaust pipe) to prevent aging and cracking;

Do not create negative pressure in the hose (such as when the water pump suddenly stops) to prevent the hose from being sucked flat and damaged;

When connecting multiple hoses, ensure that the working pressure of each hose is consistent to avoid the cracking of weak hoses due to uneven pressure.

2. Daily maintenance methods: Extending service life

(1) Cleaning after use

After irrigation, drain the residual water in the hose to avoid ice cracking in winter or bacterial growth in summer;

If fertilizer or pesticide solution has been transported, rinse the inner wall of the hose with clean water 2-3 times to remove residual corrosive substances;

Wipe the dirt and oil on the surface of the hose with a soft cloth to avoid scratching the surface with sharp tools. (2) Storage method

Storage environment: Choose a cool, dry, and ventilated warehouse to avoid direct sunlight and humid environment;

Folding method: Use "8" folding or reel storage to avoid excessive squeezing or folding (folding radius ≥ 10cm);

Avoid heavy pressure: Do not stack heavy objects on top of the hose during storage to prevent structural deformation;

Classified storage: Hoses of different specifications and materials should be stored separately to facilitate quick retrieval when next used.

(3) Regular inspection and repair

Inspect the appearance of the hose once a month. If minor damage is found, it can be repaired with special repair glue or patches;

Inspect the sealing of the interface once a quarter. If the interface is aged or deformed, it needs to be replaced in time;

Perform a water pressure test once a year to test the high-pressure resistance of the hose. If the pressure drops by more than 20%, a new hose needs to be replaced.

VI. Current status and future trends of the high-pressure irrigation hose industry

With the acceleration of agricultural modernization and the promotion of water-saving irrigation policies, the high-pressure irrigation hose industry has ushered in a period of rapid development. The following will analyze the current status of the industry and look forward to future trends.

1. Current status of industry development: scale expansion and intensified competition

(1) Continuous growth in market scale

About 20% of traditional hoses need to be replaced with high-pressure hoses every year.

(2) Concentrated regional distribution

Relying on the advantages of sufficient raw material supply and a complete industrial chain, enterprises have formed a complete industrial chain from raw material production, hose manufacturing to sales.

(3) Differentiation of the competitive landscape

Enterprises in the industry can be divided into three echelons: the first echelon is large enterprises with brand advantages and strong technical strength. Their products are mainly medium- and high-end rubber and composite hoses, with a market share of about 20%; the second echelon is medium-sized enterprises, which focus on a certain niche field (such as PVC hoses or rubber hoses), have stable product quality, and have a market share of about 30%; the third echelon is small enterprises, which mainly produce low-end PVC hoses, have low technical content, rely on price competition, and have a market share of about 50%. At present, industry competition is gradually intensifying, and small enterprises are facing elimination pressure due to the improvement of environmental protection and quality standards.

2. Challenges faced by the industry

(1) Fluctuations in raw material prices

The prices of the main raw materials for high-pressure irrigation hoses (such as PVC resin, natural rubber, and polyester yarn) are greatly affected by the international market. For example, the price of natural rubber rose by 30% year-on-year in 2022, resulting in a 15%-20% increase in the production cost of rubber hoses, which squeezed the profit margins of enterprises.

(2) Stricter environmental protection policies

In recent years, national environmental protection policies have become increasingly stringent, requiring hose manufacturers to meet waste gas and wastewater emission standards. Some small PVC hose manufacturers are facing pressure to suspend production or transform due to insufficient investment in environmental protection equipment, and the industry's environmental protection costs continue to rise.

(3) Serious product homogeneity

The phenomenon of product homogeneity in the mid- and low-end markets (especially PVC hoses) is prominent. Companies mostly rely on price competition, resulting in uneven product quality, which affects the overall image of the industry. However, the core technology of the high-end market (such as high-pressure rubber hoses) is still controlled by a few companies. Small and medium-sized enterprises lack R&D capabilities and find it difficult to break through technical barriers.

3. Future Development Trends

(1) Product Upgrade: Development towards High Performance and Multifunctionality

In the future, high-pressure irrigation hoses will focus more on performance improvement and function expansion: first, developing products with higher pressure ratings (such as 3.0MPa and above) to adapt to large-scale high-pressure irrigation systems; second, developing multifunctional hoses (such as integrated hoses with both irrigation and fertilization functions); third, promoting environmentally friendly products (such as degradable PE hoses and recycled PVC hoses) to respond to the needs of green agricultural development.

(2) Technological Innovation: Intelligent and Lightweight Development

In terms of intelligence, hoses are combined with sensors and Internet of Things technologies to develop "intelligent high-pressure hoses" to monitor parameters such as pressure, flow, and water quality in the hoses in real time, and remotely control them through mobile phone APPs to achieve precise irrigation. In terms of lightweighting, new composite materials (such as carbon fiber reinforced composite materials) are used to further reduce the weight of hoses while ensuring high-pressure resistance and improve laying flexibility. (3) Market consolidation: industry concentration increases

With stricter environmental protection policies and intensified market competition, small businesses will gradually be eliminated or merged and restructured by large enterprises, and industry concentration will increase significantly. At the same time, large enterprises will further expand their market share through brand building and channel expansion, and promote the industry to develop in the direction of standardization and high quality.

(4) Huge export market potential

High-pressure irrigation hose products have strong competitiveness in the international market due to their high cost performance. In the future, with the advancement of the "Belt and Road" initiative, companies will increase their exports to agricultural developing countries such as Southeast Asia and Africa, and the export market share is expected to increase from the current 10% to more than 20%.

VII. High-pressure irrigation hose purchase guide and brand recommendation

For users, choosing reliable brands and products is the key to ensuring the use effect. The following will provide a detailed purchase guide and recommend brands with good reputation in the market.

1. Buying Guide: Four Steps to Select High-Quality Products

(1) Clarify Demands and Determine Parameters

Before purchasing, you need to clarify the following requirements: irrigation system pressure, irrigation area, operating environment, and budget. Based on these, determine the core parameters of the hose, such as working pressure, pipe diameter, length, and material, to avoid blind purchasing.

(2) Check qualifications and ensure compliance

Choose products from companies with formal production qualifications and require product inspection reports. At the same time, check whether the product labeling is clear (including brand, specifications, working pressure, production date, etc.). Do not buy products without labeling or with unclear labeling.

(3) Sensory Identification and Preliminary Judgment

Look: Observe whether the surface of the hose is flat, free of bubbles, impurities, and uniform in color; whether the reinforcement layer is tightly and neatly woven, and without broken wires;

Touch: Touch the surface of the hose with your hand to feel whether it is smooth and burr-free; bend the hose to feel whether it is flexible and not stiff;

Smell: Smell whether the hose has a pungent odor. If the odor is obvious, it may be that inferior raw materials are used, posing environmental and safety risks.

(4) Trial test to confirm performance

If conditions permit, a trial test can be carried out: after connecting the water pump, increase the pressure to the working pressure and observe whether the hose has leakage or bulging; after turning off the water pump, check whether the hose has obvious shrinkage or deformation. At the same time, test the sealing and connection convenience of the interface.

Conclusion: High-pressure irrigation hoses contribute to the development of agricultural modernization

As the core equipment of efficient irrigation systems, high-pressure irrigation hoses play an irreplaceable role in improving agricultural production efficiency, saving water resources, and promoting the large-scale development of agriculture. With the continuous innovation of technology and the continuous upgrading of the industry, high-pressure irrigation hoses will develop in the direction of high performance, intelligence, and environmental protection.
